SDSS J024634.11−082536.2: A New Gravitationally Lensed Quasar from the Sloan Digital Sky Survey

Authors: Naohisa Inada, Scott Burles, Michael D. Gregg, Robert H. Becker, Paul L. Schechter, Daniel J. Eisenstein, Masamune Oguri, Francisco J. Castander, Patrick B. Hall, David E. Johnston, Bartosz Pindor, Gordon T. Richards, Donald P. Schneider, Richard L. White, J. Brinkmann, Alexander S. Szalay, and Donald G. York

Inada et al. 2005 The Astronomical Journal 130 1967.

Provider: AAS Journals

Caption: Fig. 9.

NICMOS F160W image (left) and the PSF‐subtracted image (right) of SDSS J0246−0825. The pixel scale is approximately 0﹩\farcs﹩075 pixel⁻¹. The central extended object (component G) is clearly seen in both the original and the PSF‐subtracted image. We can see component C forms a nearly perfect ring in the PSF‐subtracted image. This ring feature is likely to be the lensed host galaxy of the source quasar (see Fig. 12). The PSF magnitudes of components A and B are 17.3 and 18.6, respectively, and the aperture magnitude (0﹩\farcs﹩375 radius) of component G is 19.4.
