Formation and Trapping of CO2 from Cryogenic Irradiation of Carbonate

  • Authors: Ashma Pandya, Swaroop Chandra, Michael E. Brown

Ashma Pandya et al 2026 The Planetary Science Journal 7 .

  • Provider: AAS Journals

Caption: Figure 5.

Normalized IR reflectance spectra showing the thermal evolution of the CO2 ν3 doublet during warming of irradiated CaCO3 from the 50 K, high-flux experiment. Dashed lines mark the fitted central wavelengths of the two components. The 4.27 μm feature weakens by 90 K and disappears by 150 K, while the sharper 4.25 μm component remains stable up to 120 K, then diminishes, but remains detectable after 3 hr at 150 K. This behavior aligns with the RGA data (Figure 4), which show a distinct CO2 release peak around 90 K followed by broader desorption features above 110 K, and highlights multiple trapping states.
