The Next Generation Virgo Cluster Survey (NGVS). I. Introduction to the Survey

Authors: Laura Ferrarese, Patrick Côté, Jean-Charles Cuillandre, S. D. J. Gwyn, Eric W. Peng, Lauren A. MacArthur, Pierre-Alain Duc, A. Boselli, Simona Mei, Thomas Erben, Alan W. McConnachie, Patrick R. Durrell, J. Christopher Mihos, Andrés Jordán, Ariane Lançon, Thomas H. Puzia, Eric Emsellem, Michael L. Balogh, John P. Blakeslee, Ludovic van Waerbeke, Raphaël Gavazzi, Bernd Vollmer, J. J. Kavelaars, David Woods, Nicholas M. Ball, S. Boissier, Stéphane Courteau, E. Ferriere, G. Gavazzi, Hendrik Hildebrandt, P. Hudelot, M. Huertas-Company, Chengze Liu, Dean McLaughlin, Y. Mellier, Martha Milkeraitis, David Schade, Chantal Balkowski, Frédéric Bournaud, R. G. Carlberg, S. C. Chapman, Henk Hoekstra, Chien Peng, Marcin Sawicki, Luc Simard, James E. Taylor, R. Brent Tully, Wim van Driel, Christine D. Wilson, Todd Burdullis, Billy Mahoney, and Nadine Manset

Ferrarese et al. 2012 The Astrophysical Journal Supplement Series 200 4.

Provider: AAS Journals

Caption: Figure 15.

Magnified view of a stacked g-band NGVS image showing a 10′ × 10′ region located in the Virgo cluster core. This field is located approximately 40′ (~200 kpc) to the northwest of M87. Two early-type dwarf galaxies from the VCC of Binggeli et al. (1985) are shown by the cyan ellipses: VCC1129 and VCC1104 ( g ≈ 17.7 mag and 15.4 mag, respectively). The yellow ellipses show a number of faint, low surface brightness dwarfs that are probable cluster members based on sizes, surface brightness, and colors; the small galaxy to the southeast of VCC1129 (also detected by Lieder et al. 2012) has in fact recently been spectroscopically confirmed as a cluster member by our team. These newly discovered galaxies have magnitudes in the range 18.7 mag < g < 24.9 mag and effective surface brightnesses of 24.3 mag arcsec ⁻² < lang μ _g rang _e < 28.8 mag arcsec ⁻².
