The Gold Standard: Accurate Stellar and Planetary Parameters for Eight Kepler M Dwarf Systems Enabled by Parallaxes

Authors: Andrew W. Mann, Trent Dupuy, Philip S. Muirhead, Marshall C. Johnson, Michael C. Liu, Megan Ansdell, Paul A. Dalba, Jonathan J. Swift, and Sam Hadden

2017 The Astronomical Journal 153 267.

Provider: AAS Journals

Caption: Figure 5.

Comparison of eccentricity posteriors for Kepler-42bcd when fitting each planet individually (blue) or fitting simultaneously, forcing common limb-darkening parameters and stellar density (red). Bin sizes and locations are identical. The median of each distribution is shown with a vertical dashed line with the appropriate color.
